Shenzhen Zhisheng Technology Co., Ltd
9 Years
| Ask Lasest Price | |
| Brand Name : | ZS |
| Certification : | UL,ROHS,CE,ISO9001 |
| Model Number : | 9225 |
| Price : | $0.37-$4.45 |
| Delivery Time : | 7-10 days |
| Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 1000,000pcs |
Size:92x92x25mm
| Application: | Other | Type: | Fan | Heatsink Material: | Copper & Aluminum |
| Brand Name: | others | Model Number: | 9225 | Place of Origin: | GUA,Guangdong China (Mainland) |
| Dimensions: | 92*92*25mm | Lifetime: | 70,000hours for ball bearing and 30,000hour year for seleeve
bearing | Heastink material: | copper & aluminum |
| Impeller: | PBT | Terminal: | yes/no | Square wave output: | yes/no |
| MOQ: | 100 pcs | Wire number: | 4-wire 3-wire or 2-wire |
| Model | Bearing | Rated | Operation | Current | Input | Speed | Air Flow | Static | Niose | Weight |
| System | Voltage | Voltage | power | Pressure | Level | |||||
| (V) | (V) | (A) | (W) | (RPM) | (CFM) | (mm-H2O) | (dB-A) | (g) | ||
| (型号) | (培林) | (电压) | (电压范围) | (电流) | (功率) | (转速) | (风量) | (静压) | (噪音) | (重量) |
| 9225 | 12 | 10.8～13.2 | 0.25 | 3.00 | 2800 | 54.73 | 3.04 | 32.81 | 85 | |
| Sleeve | 0.20 | 2.40 | 2500 | 46.46 | 2.11 | 28.58 | 85 | |||
| 0.16 | 1.92 | 2000 | 39.87 | 1.67 | 25.87 | 85 | ||||
| 0.25 | 3.00 | 2800 | 54.73 | 3.04 | 32.81 | 85 | ||||
| Ball | 0.20 | 2.40 | 2500 | 46.46 | 2.11 | 28.58 | 85 | |||
| 0.16 | 1.92 | 2000 | 39.87 | 1.67 | 25.87 | 85 | ||||
| 24 | 21.6～26.4 | 0.15 | 3.60 | 2800 | 54.73 | 3.04 | 32.81 | 85 | ||
| Sleeve | 0.10 | 2.40 | 2500 | 46.46 | 2.11 | 28.58 | 85 | |||
| 0.07 | 1.68 | 2000 | 39.87 | 1.67 | 25.87 | 85 | ||||
| 0.15 | 2.64 | 2800 | 54.73 | 3.04 | 32.81 | 85 | ||||
| Ball | 0.10 | 2.40 | 2500 | 46.46 | 2.11 | 28.58 | 85 | |||
| 0.07 | 1.68 | 2000 | 39.87 | 1.67 | 25.87 | 85 |
Advantages:
1. Delivery lead time: 7-10 work days
2. Reliable quality as well as Competitive price
3. Function: FG,RD,PWM , Automatic Restart can be choice
4. Waterproof grade: IPX1~IPX8, such as IP55,IP67,IP68
5. OEM&ODM
6. Certificate: CE/RoHS/UL
7. Life Expectancy: Dual Ball Bearing 50000 hours ,Sleeve Bearing 3000 hours
8. Dimension: 20mm-280mm Thickness: 7mm-38mm
9. Best service by our sales and engineers
